Geometry

  Small Medium Large Extra Large
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 530 522 512 599
Stack 699 737 704 741
Top Tube (effective) 678 538 608 731
Seat Tube C-T 391 363 508 557
Head Angle 51 72 70 57
Seat Angle 68 85 86 82
Head Tube 100 95 127 117
Chainstay 374 419 522 397
Wheelbase 1261 1094 1171 1325
Standover 542 577 707 723
BB Drop 21 22 18 16
BB Height 290 372 394 293
Front Travel 152 143 147 198
Rear Travel 177 177 158 191
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
