Geometry

  S(48) M(51) L(54) XL(57)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 601 655 481 507
Seat Tube C-C 449 471 508 653
Head Angle 82 66 66 87
Seat Angle 66 65 80 73
Head Tube 107 97 122 132
Frame Weight 1102 1265 1179 1423
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Note: External headset will add ~30mm equivalent to head tube length depending on headset choice.

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
