Geometry

  54 56 58 60
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 380 467 418 487
Stack 504 594 621 714
Top Tube (effective) 628 549 604 554
Seat Tube C-T 517 470 440 464
Head Angle 76 59 77 67
Seat Angle 77 83 83 67
Head Tube 149 175 138 203
Chainstay 504 362 387 519
Wheelbase 1030 902 1196 1146
BB Drop 75 67 78 83
Fork Rake / Offset 53 57 52 53
Fork Length (A2C) 372 445 335 378
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
