Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 477 374 490 548
Stack 699 544 665 690
Top Tube (effective) 618 729 682 737
Seat Tube C-T 362 416 487 465
Head Angle 66 63 68 70
Seat Angle 67 62 60 72
Head Tube 118 132 110 155
Chainstay 354 378 399 372
Wheelbase 1124 1071 1394 1477
BB Drop 40 51 43 44
BB Type 73mm BSA 73mm BSA 73mm BSA 73mm BSA
Wheel Size 27 29 23 25
Front Travel 161 161 155 137
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
