Geometry

  Small Medium Large X Large
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 548 513 466 553
Seat Tube C-T 471 476 583 600
Seat Tube C-C 454 553 513 616
Head Angle 71 57 63 83
Seat Angle 70 64 60 60
Head Tube 173 143 179 217
Chainstay 384 432 440 407
Wheelbase 900 1251 1217 1010
BB Drop 89 60 60 77
Fork Rake / Offset 55 47 57 40
Fork Length (A2C) 450 503 406 338
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
