Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 315 362 377 376 338
Stack 465 524 610 526 674
Top Tube (effective) 573 494 559 579 672
Seat Tube C-C 517 499 611 428 601
Head Angle 57 58 75 68 67
Seat Angle 60 60 66 73 79
Head Tube 113 112 129 182 216
Wheelbase 988 870 946 1039 1221
Front Centre 680 566 693 718 590
BB Drop 79 69 59 75 72
Fork Rake / Offset 48 44 48 48 50
Rider Height 5'3 - 5'7 (159 - 169cm) 5'6 - 5'9 (167 - 176cm) 5'9 - 5'11 (174 - 181cm) 5'10 - 6'1 (179 - 186cm) 6'0 - 6'4 (184 - 193cm)
Saddle Height 699 583 816 673 727
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
