Geometry

  XS S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 357 407 471 435
Stack 620 516 579 690
Top Tube (effective) 465 627 491 680
Seat Tube C-T 523 441 507 592
Head Angle 79 64 71 83
Seat Angle 78 66 63 81
Head Tube 89 117 176 189
Chainstay 499 441 342 404
Wheelbase 872 856 950 1212
Standover 803 719 694 900
BB Drop 86 94 70 68
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
