Geometry

  XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 411 382 372 369 366 415
Stack 433 463 470 654 669 599
Top Tube (effective) 415 485 574 653 464 686
Seat Tube C-T 455 426 514 451 628 636
Head Angle 62 64 67 73 84 80
Seat Angle 76 85 81 58 83 74
Head Tube 110 129 139 173 200 177
Chainstay 476 455 339 429 457 428
Wheelbase 953 1010 808 809 1093 1012
BB Drop 83 63 84 75 73 65
Fork Rake / Offset 47 53 43 51 45 48
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
