Geometry

  S (29") S (27.5") M (27.5") M (29") L (29") L (27.5") XL (27.5") XL (29")
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 341 333 486 435 478 526 508 544
Stack 532 568 508 587 670 501 695 521
Top Tube (effective) 529 656 653 662 613 701 594 603
Seat Tube C-T 412 435 465 352 454 447 513 478
Head Angle 71 70 78 82 66 62 70 73
Seat Angle 69 85 78 60 66 79 64 61
Head Tube 115 90 110 122 125 125 144 155
Chainstay 361 502 483 457 361 443 482 370
Wheelbase 1246 1234 1117 1255 1351 1263 1325 1349
BB Drop 54 47 46 42 41 57 44 50
BB Height 348 314 360 275 368 295 347 366
Fork Rake / Offset 55 42 39 42 43 44 50 45
Fork Length (A2C) 439 528 471 593 549 583 471 595
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
