Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 407 428 441 471 372
Stack 549 514 492 639 644
Top Tube (effective) 596 473 524 501 609
Seat Tube C-C 491 439 602 517 658
Head Angle 81 81 80 82 83
Seat Angle 65 65 86 63 78
Head Tube 115 110 131 187 204
Chainstay 460 376 368 473 342
Front Centre 499 549 578 663 685
BB Drop 81 74 68 64 65
Fork Rake / Offset 60 65 53 52 63
Fork Length (A2C) 338 313 425 358 464
Handlebar Width 348 423 383 365 501
Stem Length 73 92 102 96 118
Crank Length 138 159 139 152 197
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Note: HI geometry setting
