Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 312 307 362 434 361
Stack 470 583 506 563 517
Top Tube (effective) 623 498 490 559 685
Seat Tube C-C 492 397 523 592 607
Head Angle 83 70 82 60 68
Seat Angle 86 68 79 87 81
Head Tube 101 113 129 186 201
Chainstay 411 447 354 359 376
Front Centre 664 495 663 659 609
BB Drop 74 75 68 76 81
Fork Rake / Offset 53 46 40 45 41
Fork Length (A2C) 466 375 391 448 426
Handlebar Width 425 336 505 360 529
Stem Length 76 72 77 82 102
Crank Length 192 159 175 203 200
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
