Geometry

  50 53 55 57 59 62
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 320 454 324 437 378 444
Stack 563 441 452 484 661 548
Top Tube (effective) 457 563 544 484 634 664
Seat Tube C-T 506 482 568 457 625 521
Head Angle 58 79 82 73 58 78
Seat Angle 75 61 75 78 76 79
Head Tube 122 134 145 149 152 211
Chainstay 338 420 429 429 467 384
Wheelbase 857 928 887 1168 985 1043
Front Centre 606 483 629 593 615 580
Standover 869 715 896 860 507 766
BB Drop 68 67 68 57 65 69
Fork Rake / Offset 48 43 40 43 38 38
Seatpost Diameter 28 30 25 23 24 30
Wheel Size 700c 700c 700c 700c 700c 700c
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
