Geometry

  SM MD LG XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 456 331 454 457
Stack 705 670 760 756
Top Tube (effective) 574 597 710 628
Seat Tube C-T 340 382 488 603
Head Angle 59 75 78 55
Seat Angle 75 80 68 63
Head Tube 86 128 135 129
Chainstay 525 572 548 459
Wheelbase 1010 1301 960 1441
Standover 591 633 785 981
BB Drop 120 101 95 90
Fork Rake / Offset 47 52 56 42
Wheel Size 36 26 28 26
Rider Height 157.0 – 170.0 168.0 – 180.0 178.0 – 191.0 188.0 – 201.0
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Note: Pre-release geometry

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
