Geometry

  XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 425 446 438 446 345 358 428
Stack 447 587 614 616 636 672 631
Top Tube (effective) 506 470 630 610 601 467 554
Seat Tube C-T 368 468 543 445 511 615 493
Seat Tube C-C 480 2 4 12 15 19 40
Head Angle 84 64 79 73 58 69 63
Seat Angle 67 76 67 81 77 86 82
Head Tube 85 105 131 134 190 196 254
Chainstay 492 397 473 457 385 360 335
Wheelbase 1161 1091 1070 1001 1038 998 833
Standover 780 816 816 641 937 938 995
BB Drop -64 -65 -74 -59 -59 -76 -84
BB Height 223 248 263 322 246 289 226
Fork Rake / Offset 40 53 46 55 45 40 42
Handlebar Width 320 345 350 376 345 471 470
Stem Length 73 75 77 81 82 112 125
Crank Length 172 141 177 173 157 151 192
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Note: Endurance geometry
