Geometry

  XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 309 430 442 337 367 392 333
Stack 446 441 492 652 599 618 741
Top Tube (effective) 413 532 451 605 574 534 658
Head Angle 70 76 64 82 64 69 69
Seat Angle 86 89 60 66 60 69 72
Head Tube 76 117 104 154 140 152 211
Chainstay 397 375 502 457 347 348 347
Wheelbase 883 926 970 1146 960 1022 1033
Standover 616 663 744 723 757 790 879
BB Drop -71 -67 -61 -82 -75 -82 -69
BB Height 291 299 229 307 255 286 286
BB Type BB-RS500-PB BB-RS500-PB BB-RS500-PB BB-RS500-PB BB-RS500-PB BB-RS500-PB BB-RS500-PB
Stem Length 85 111 107 122 126 133 126
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
