Geometry

  XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 359 348 446 346 470 437 449
Stack 450 430 562 666 579 532 581
Top Tube (effective) 606 525 500 467 681 676 581
Head Angle 74 57 84 84 63 70 80
Seat Angle 83 62 67 82 75 62 63
Head Tube 94 91 137 171 166 221 222
Chainstay 417 347 492 397 340 486 362
Wheelbase 854 803 1166 931 954 880 1105
Standover 746 761 888 807 678 835 839
BB Drop -80 -77 -59 -70 -58 -76 -72
BB Height 323 231 221 228 269 243 258
Stem Length 61 66 83 85 93 106 96
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
