Geometry

  XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 321 440 374 417 409 393 394
Stack 592 519 588 651 605 613 554
Top Tube (effective) 622 528 579 570 605 677 587
Seat Tube C-T 503 523 374 548 419 576 481
Seat Tube C-C 401 497 540 561 457 435 537
Head Angle 83 59 72 71 71 80 80
Seat Angle 74 84 78 86 81 83 68
Head Tube 91 118 125 108 152 201 168
Chainstay 404 470 417 474 394 383 484
Wheelbase 963 1005 1006 949 809 944 848
Standover 633 757 699 763 769 724 1004
BB Drop -69 -80 -82 -58 -71 -69 -81
BB Height 227 320 249 280 265 302 255
Fork Rake / Offset 52 43 43 38 52 37 42
Handlebar Width 337 406 367 430 331 425 465
Stem Length 93 90 100 123 114 109 140
Crank Length 185 152 196 177 150 142 199
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
