Geometry

  17" 19" 21" 23"
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 352 339 406 420
Stack 699 695 660 650
Top Tube (effective) 494 619 665 564
Seat Tube C-T 348 566 611 699
Head Angle 72 63 58 68
Seat Angle 75 61 81 69
Head Tube 101 117 116 121
Wheelbase 1068 1063 1319 1173
Fork Rake / Offset 42 52 36 39
Axle to Crown 590 572 544 497
Wheel Size 29er 29er 29er 29er
Data Source Sensa Sensa Sensa Sensa

Measurements are in millimeters and degrees.
