Geometry

  Small Medium Large Extra Large
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 424 440 499 349
Stack 593 492 739 693
Top Tube (effective) 683 605 590 643
Seat Tube C-T 404 435 432 568
Head Angle 80 66 81 75
Seat Angle 71 73 64 61
Head Tube 93 84 133 122
Chainstay 393 476 436 520
Wheelbase 1207 1179 989 1003
Front Centre 585 784 643 641
BB Drop 58 75 55 54
BB Type 73mm EBB 73mm EBB 73mm EBB 73mm EBB
Fork Rake / Offset 51 55 50 56
Axle to Crown 559 469 519 510
Seatpost Diameter 27 25 27 32
Wheel Size 29er 29er 29er 29er
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
