Geometry

  48CM 50CM 52CM 54CM 56CM
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 310 456 430 405 460
Stack 485 537 514 534 616
Top Tube (effective) 587 442 512 524 482
Seat Tube C-T 431 406 515 626 670
Head Angle 57 81 61 69 59
Seat Angle 83 78 68 68 61
Head Tube 105 114 116 174 197
Chainstay 423 332 331 488 479
Wheelbase 1105 1060 1114 1125 1108
BB Drop 79 81 65 56 71
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
