| S | M | L | XL | |
|---|---|---|---|---|
| Add to Compare | ||||
| Reach | 474 | 442 | 512 | 414 |
| Stack | 679 | 656 | 553 | 696 |
| Top Tube (effective) | 499 | 748 | 703 | 586 |
| Top Tube (actual) | 747 | 757 | 640 | 655 |
| Seat Tube C-T | 301 | 359 | 528 | 553 |
| Head Angle | 67 | 70 | 71 | 66 |
| Seat Angle | 61 | 64 | 70 | 69 |
| Head Tube | 101 | 109 | 102 | 130 |
| Chainstay | 506 | 382 | 403 | 409 |
| Wheelbase | 1199 | 1010 | 1315 | 1282 |
| BB Drop | 56 | 61 | 72 | 59 |
| Fork Rake / Offset | 40 | 36 | 41 | 34 |
| Fork Length (A2C) | 500 | 599 | 524 | |
| Seatpost Diameter | 26 | 32 | 29 | 27 |
| Wheel Size | 27,5″ | 29" | 29" | 29" |
| Tyre Max Width | 2.5“ | 2.5“ | 2.5“ | |
| Max Post Insertion | 285 | 248 | 278 | 252 |
| Front Travel | 121 | 120-140 | 120-140 | 120-140 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Note: static
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
