Geometry

  49 52 54 56 58 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 323 408 457 357 471 365
Stack 578 563 601 630 517 655
Top Tube (effective) 489 627 484 482 681 483
Seat Tube C-T 489 462 573 457 617 620
Head Angle 78 58 76 59 64 64
Seat Angle 89 76 69 71 75 64
Head Tube 92 140 154 150 235 235
Chainstay 419 416 366 369 487 447
Wheelbase 786 1170 803 852 889 958
Front Centre 507 578 677 615 531 500
Standover 684 598 705 811 955 982
BB Height 219 265 308 245 266 233
Fork Rake / Offset 40 50 41 38 46 37
Trail 57 64 55 54 48 59
Fork Length (A2C) 369 432 388 440 397 407
Seatpost Length 266 308 383 371 348 370
Stem Length 68 83 68 64 76 65
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
