Geometry

  48PC™ 50PC™ 52PC™ 54 56 58 60
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 335 310 391 367 365 430 328
Stack 538 430 599 475 585 584 668
Top Tube (effective) 471 422 516 468 455 588 591
Seat Tube C-T 382 459 459 440 441 486 685
Head Angle 60 72 76 62 61 75 72
Seat Angle 86 69 86 74 79 65 82
Head Tube 102 100 107 140 129 188 172
Chainstay 500 385 495 470 414 431 361
Wheelbase 844 969 1174 955 1152 982 1235
Standover 692 818 693 710 657 885 944
Seatpost Offset 0 0 0 0 16 21 19
Handlebar Width 36 40 38 44 35 48 39
Stem Length 83 88 116 92 101 119 125
Crank Length 148 136 167 165 144 140 188
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
