| 48 | 51 | 54 | 56 | |
|---|---|---|---|---|
| Add to Compare | ||||
| Reach | 453 | 328 | 416 | 483 |
| Stack | 578 | 672 | 506 | 634 |
| Top Tube (effective) | 417 | 447 | 638 | 660 |
| Top Tube (actual) | 420 | 501 | 484 | 663 |
| Seat Tube C-T | 389 | 462 | 571 | 574 |
| Seat Tube C-C | 364 | 379 | 398 | 518 |
| Seat Tube (effective) | 542 | 573 | 614 | 733 |
| Head Angle | 59 | 63 | 81 | 78 |
| Seat Angle | 80 | 59 | 70 | 67 |
| Head Tube | 101 | 137 | 132 | 172 |
| Chainstay | 511 | 413 | 436 | 407 |
| Wheelbase | 1019 | 889 | 976 | 1164 |
| Front Centre | 709 | 682 | 526 | 635 |
| Standover | 769 | 827 | 661 | 908 |
| BB Drop | 76 | 59 | 57 | 62 |
| BB Height | 272 | 263 | 274 | 323 |
| Fork Rake / Offset | 38 | 44 | 47 | 37 |
| Fork Length (A2C) | 444 | 420 | 489 | 412 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
