Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 407 484 442 549
Stack 635 693 528 669
Top Tube (actual) 605 694 553 598
Seat Tube (effective) 362 497 494 524
Head Angle 73 55 61 55
Seat Angle 79 72 80 73
Head Tube 76 109 118 116
Chainstay 412 414 476 449
BB Drop 45 38 46 36
BB Height 393 383 347 306
Fork Rake / Offset 48 37 39 47
Front Travel 126 110 104 99
Rear Travel 103 100 104 109
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
