| S | M | L | XL | XXL | |
|---|---|---|---|---|---|
| Add to Compare | |||||
| Reach | 354 | 445 | 408 | 463 | 445 |
| Stack | 429 | 568 | 635 | 534 | 667 |
| Top Tube (effective) | 459 | 452 | 552 | 635 | 645 |
| Seat Tube C-T | 455 | 534 | 467 | 456 | 611 |
| Head Angle | 64 | 73 | 59 | 83 | 69 |
| Seat Angle | 65 | 80 | 76 | 80 | 65 |
| Head Tube | 138 | 143 | 176 | 172 | 197 |
| Chainstay | 388 | 334 | 368 | 438 | 485 |
| Wheelbase | 1004 | 1045 | 1001 | 1142 | 976 |
| Front Centre | 582 | 620 | 576 | 559 | 575 |
| Standover | 650 | 766 | 906 | 713 | 897 |
| BB Drop | 74 | 79 | 61 | 71 | 70 |
| BB Type | T47 | T47 | T47 | T47 | T47 |
| Fork Rake / Offset | 38 | 52 | 41 | 54 | 38 |
| Fork Length (A2C) | 351 | 389 | 353 | 352 | 330 |
| Seatpost Diameter | 24 | 25 | 22 | 27 | 24 |
| Wheel Size | 700C | 700C | 700C | 700C | 700C |
| Handlebar Width | 431 | 372 | 335 | 443 | 453 |
| Stem Length | 78 | 86 | 90 | 83 | 110 |
| Crank Length | 156 | 188 | 167 | 160 | 160 |
| Rider Height | 158-168 | 166-174 | 172-178 | 177-185 | 183-193 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
