Geometry

  SM MD LG XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 390 480 361 518
Stack 655 604 658 613
Top Tube (effective) 567 586 590 660
Top Tube (actual) 485 671 563 721
Seat Tube C-T 425 419 442 578
Head Angle 63 70 80 77
Seat Angle 83 64 84 81
Head Tube 90 135 107 158
Chainstay 525 405 487 441
Wheelbase 1031 1246 1173 991
Standover 896 923 798 827
BB Drop 54 60 65 67
Fork Rake / Offset 44 44 46 41
Fork Length (A2C) 370 382 410 510
Stem Length 62 74 99 104
Stem Angle 6° 6° 6° 6°
Crank Length 153 164 141 187
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
