Geometry

  56
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 547
Head Angle 58
Seat Angle 63
Chainstay 489
Wheelbase 1072
Fork Rake / Offset 50
Trail 44
Data Source Dave 'Pinnah' Mann

Measurements are in millimeters and degrees.
