| M/17.5"/ HIGH | M/17.5"/ LOW | M/L/18.5"/HIGH | M/L/18.5"/LOW | L/19.5"/HIGH | L/19.5"/LOW | XL/21.5"/HIGH | XL/21.5"/LOW | |
|---|---|---|---|---|---|---|---|---|
| Add to Compare | ||||||||
| Reach | 470 | 493 | 505 | 500 | 539 | 534 | 529 | 554 |
| Stack | 571 | 642 | 690 | 746 | 665 | 663 | 773 | 779 |
| Top Tube (effective) | 566 | 569 | 710 | 706 | 538 | 658 | 740 | 627 |
| Seat Tube C-T | 425 | 445 | 477 | 410 | 377 | 492 | 572 | 564 |
| Seat Tube (effective) | 90 | 67 | 76 | 71 | 68 | 74 | 76 | 71 |
| Head Angle | 72 | 67 | 72 | 61 | 74 | 51 | 59 | 70 |
| Seat Angle | 67.1° | 66.6° | 67.1° | 66.6° | 67.1° | 66.6° | 67.1° | 66.6° |
| Head Tube | 119 | 104 | 103 | 86 | 131 | 108 | 164 | 156 |
| Chainstay | 376 | 479 | 505 | 376 | 441 | 420 | 379 | 386 |
| Wheelbase | 1258 | 1081 | 1048 | 1222 | 1020 | 1074 | 1506 | 1476 |
| Standover | 654 | 599 | 855 | 862 | 749 | 734 | 634 | 811 |
| BB Drop | 26 | 25 | 18 | 23 | 21 | 31 | 17 | 34 |
| BB Height | 401 | 310 | 407 | 392 | 290 | 395 | 408 | 319 |
| Fork Rake / Offset | 51 | 35 | 48 | 37 | 38 | 40 | 48 | 36 |
| Axle to Crown | 544 | 622 | 707 | 680 | 556 | 677 | 630 | 694 |
| Wheel Size | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Tyre Max Width | 29x2.50 | 29x2.50 | 29x2.50 | 29x2.50 | 29x2.50 | 29x2.50 | 29x2.50 | 29x2.50 |
| Dopper Post Travel | 160 | 136 | 158 | 159 | 158 | 153 | 195 | 189 |
| Crank Length | 165 | 185 | 155 | 193 | 178 | 141 | 172 | 186 |
| Front Travel | 197 | 137 | 160 | 185 | 177 | 150 | 143 | 198 |
| Rear Travel | 159 | 142 | 145 | 181 | 137 | 162 | 142 | 149 |
| Shock Size | 230 x 62.5 | 230 x 62.5 | 230 x 62.5 | 230 x 62.5 | 230 x 62.5 | 230 x 62.5 | 230 x 62.5 | 230 x 62.5 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
