Geometry

  S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 393 386 396
Stack 734 689 660
Seat Tube C-T 344 449 350
Head Angle 76 54 62
Seat Angle 82 62 63
Head Tube 103 90 110
Chainstay 482 457 392
Wheelbase 1269 1292 1458
BB Drop 25 25 20
BB Type BSA 73mm BSA 73mm BSA 73mm
Fork Rake / Offset 39 50 47
Fork Length (A2C) 500 553 451
Seatpost Length 157 174 211
Headset ZS44/ZS56 ZS44/ZS56 ZS44/ZS56
Data Source Testpilot Testpilot Testpilot

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
