Geometry

  Court Moyen Moyen Long Long
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 457 373 371 448
Stack 627 750 504 636
Top Tube (effective) 470 582 622 541
Seat Tube C-C 339 409 422 524
Head Angle 74 62 72 60
Seat Angle 76 87 61 79
Head Tube 86 105 122 132
Chainstay 445 429 384 343
Wheelbase 1327 1290 1084 1462
BB Drop -55 -59 -51 -44
Axle to Crown 530 623 629 600
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
