Geometry

  520 540 560 575 590
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 376 373 396 456 341
Stack 588 508 508 665 594
Top Tube (effective) 611 463 529 615 610
Seat Tube (effective) 540 618 460 556 579
Head Angle 83 58 83 71 68
Seat Angle 87 81 71 68 59
Head Tube 147 159 181 194 203
Chainstay 325 486 445 354 367
Wheelbase 901 818 893 1127 1121
Front Centre 555 595 558 692 719
BB Drop 70 64 69 66 61
Fork Rake / Offset 48 49 49 41 37
Trail 59 71 69 64 54
Fork Length (A2C) 336 429 391 428 399
Wheel Size 700c 700c 700c 700c 700c
Data Source Viathon Viathon Viathon Viathon Viathon
