Geometry

  XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 341 413 398 436 385 425
Stack 588 516 456 510 543 636
Top Tube (effective) 576 481 455 589 594 546
Seat Tube C-C 384 449 439 466 635 491
Head Angle 58 78 78 83 69 68
Seat Angle 71 76 70 79 65 72
Head Tube 107 110 120 167 180 200
Chainstay 355 370 359 402 334 361
Wheelbase 1093 1166 816 1173 1191 1023
Standover 712 670 895 715 661 712
BB Drop 66 80 72 60 75 83
BB Height 302 249 284 256 307 217
BB Type T47-85.5 T47-85.5 T47-85.5 T47-85.5 T47-85.5 T47-85.5
Fork Rake / Offset 55 53 47 50 51 41
Trail 65 65 67 52 69 51
Fork Length (A2C) 324 304 405 340 316 371
Wheel Size 700x32 700x32 700x32 700x32 700x32 700x32
Seatpost Length 356 320 410 299 408 366
Seatpost Offset 0 0 15 17 14 13
Rider Height 155-163 163-170 170-178 178-185 185-193 193-200
Data Source Winspace Winspace Winspace Winspace Winspace Winspace
