Geometry

  XXS XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 322 336 376 338 403 344 355
Stack 494 554 615 494 608 503 749
Top Tube (effective) 427 447 619 628 608 601 634
Top Tube (actual) 502 587 537 622 638 550 510
Seat Tube C-T 348 541 439 578 607 575 726
Head Angle 72o 72.5o 73o 73.5o 73.5o 73.5o 73.5o
Seat Angle 75.5o 75o 74.5o 74o 73.5o 73.5o 73.5o
Head Tube 87 105 131 168 159 147 187
Chainstay 394 484 384 421 390 394 389
Wheelbase 922 931 1144 1172 965 821 1088
Front Centre 585 534 644 672 487 624 586
BB Drop 76 63 69 79 79 82 82
Rider Height < 164cm 162-168cm 165-172cm 171-180cm 178-186cm 184-192cm > 190cm
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
