Geometry

  M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 363 398 354 459
Stack 647 513 543 664
Top Tube (effective) 479 623 646 640
Top Tube (actual) 621 624 507 609
Head Angle 81 77 60 63
Seat Angle 61 75 69 65
Head Tube 148 146 202 223
Chainstay 500 380 475 361
Wheelbase 1033 1249 1205 938
Front Centre 562 625 723 669
Standover 923 897 873 956
BB Drop 81 74 79 68
BB Type T47 T47 T47 T47
Seatpost Diameter 24 29 30 29
Tyre Max Width 700 x 55 700 x 55 700 x 55 700 x 55
Crank Length 189
Seat Clamp 35 25 29 34
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
